1、額定速度:V:0.5m/s-1.75m/s(CE)
0.25m/s-2.0m/s、2.5m/s(GB)
2、鋼絲繩漲緊力:F:800N-1500N
3、鋼絲繩直徑:Φ8mm
4、繩輪節(jié)圓直徑:Φ240mm
5、提升高度H適應范圍:
a)張緊裝置漲緊力250N:H≤60m;
b)張緊裝置漲緊力350N:60m<H≤80m;
c)張緊裝置漲緊力450N:80m<H≤120m。
1.Rated speed:V:0.5m/s-1.75m/s(CE)
0.25m/s-2.0m/s、2.5m/s(GB)
2.Rope tension:F:800N-1500N
3.Diameter of wire rope:Φ8mm
4.The rope round the pitch diamete:Φ240mm
5.Adapted to the scope of hoisting height :
a)Tensioning device of tight force:250N, H≤60m;
b)Tensioning device of tight force:350N,60m<H≤80m;
c)Tensioning device of tight force:450N,80m<H≤120m
