1、額定速度:0.5-1.75m/s
2、鋼絲繩漲緊力:750±250N
3、鋼絲繩直徑:Φ0 6mm
4、繩輪節(jié)圓直徑:Φ200mm
5、電梯提升高度:H≤80M
漲緊裝置漲緊力:300N
6、電磁鐵參數(shù):標(biāo)配直流DC24V
選配交流AC220V
1.Rated speed:0.5-1.75m/s
2.Rope tension:750±250N
3.Diameter of wire rope:Φ0 6mm
4.The rope round the pitch diamete:Φ200mm
5.The elevator lifting height:H≤80M
Tensioning device of tight force:300N
6.Electromagnet parameters:Standard DC24V
Matching AC220V
